Double-sided Taconic Immersion gold PCB

Product Material:Taconic TLY-5ANumber of Layers:2 LayersPCB Size:152.4*90.42mmMin. Hole Size:0.3mm
Quote Now
Product Details
Double-sided Taconic Immersion gold PCB

Product Specification:

No. Category Details
1 Product Name Double-sided Taconic Immersion gold PCB
2 Product Material Taconic TLY-5A
3 Number of Layers 2 Layers
4 PCB Size 152.4*90.42mm
5 Min. Hole Size 0.3mm
6 Board Thickness 0.94mm
7 Minimum Line Width 1.046mm
8 Minimum Line Spacing 1.046mm
9 Surface Finish Immersion Gold

Our Advantages:

( With more than ten years of PCB fabrication and assembly experience)
1. We have our own PCB circuit board and SMT assembly factory
2. One-on-one assistance, Smooth shopping experience
3. Free DFM and Electrical test & components cost-down
4. We will refund if the PCB quality is not good as described or is with defects
5. Certification: 94v-0, CE, SGS, FCC, RoHS, ISO9001:2008, ISO14001

Advanced PCB Capabilities:



 Process capability parameter

1 Board Type
Rigid PCB
2 Base Material
See Below “Material” Chart
3 Number of Layers 1-50 Layers
4 Min Trace Width/Spacing Inner Layer
2/ 2mil
5 Min trace width/spacing Outer Layer
2.5/ 2.5mil
6 Finished Copper Thickness
0.5-8 oz
7 Min Spacing Between Hole to Inner Layer Conductor
8 Min Spacing Between Hole to Outer Layer Conductor
9 Min Annular Ring for Component Hole
10 Min Annular Ring for Via
11 Min BGA Pitch
12 Min BGA Diameter
13 Min Hole Size
0.15mm(CNC)|0.1mm(Laser Blind)
14 Max Aspect Ratio
15 Soldermask / Circuit Processing Method
Film | LDI
16 Min Soldermask Bridge Width
17 Min Thickness for Insulating Layer
18 Max PCB size
19 HDI & Special Type PCB

HDI(1-3 steps), Buried capacitance, High frequency mix-pressing (2-14 layers) & resistance, etc.

20 Surface Finish
HASL, HASL lead free, Immersion gold(ENIG), Immersion Tin, OSP, Immersion Silver(Ag), Plating Hard Gold

PCB Application:

PCB Application


PCB Package and Delivery


1,What files are necessary for us to assembly PCBs for you?

1.1 PCB files(Gerber files)

1.2 BOM(Bill of components)

1.3 Cendroid files/Pick&place files)

1.4 Assembly drawings

In order to ensure the quality, BOM files must be clearly noted specific part number,Brand’s very important for us to purchase right components for your project.

2. Is there a minimum order quantity?

There is no MOQ in AllWinPcba.

3. Shipping Cost?

The shipping cost is determined by the destination, weight, packing size of the goods. Please let us know if you need us to quote you the shipping cost.

4. Which payment terms do you accept?

we usually accept the following payment terms T/T, western union, money gram, Paypal, and if a Larger amount, we also accept L/C and so on. you can also tell us about your payment way!

Choose AllWinPcba for your Double-sided

AllWinPcba is a professional printed circuit board supplier, with rich manufacturing experience in the advanced PCB, and supports PCB proofing and mass production. Products can be widely used in mobile phones, microwave, aerospace, satellite communications, network base stations, hybrid integrated circuits, power high-power circuits and other high-tech fields.  PCB factory, welcome your inquiry about our advanced PCB

Advanced PCB Online Quote
