Electronic pcb manufacturer One-stop service Electronic assembly pcb design factory OEM Fr4 pcb

原图
Electronic pcb manufacturer One-stop service Electronic assembly pcb design factory OEM Fr4 pcb board FR-4 Process capabilityItemCraft AbilitySurface FinishHAS…
Quote Now
Product Details

Electronic pcb manufacturer One-stop service Electronic assembly pcb design factory OEM Fr4 pcb board


pcb design factory OEM Fr4 pcb board

                                      FR-4 Process capability

Item

Craft Ability

Surface Finish

HASL,Immersion Gold,Gold Plating,OSP,Immersion Tin,etc

Layer

1-32 layers

Min.Line Width

4mil

Min.Line Space

4mil

Min.Space between Pad to Pad

3mil

Min.Hole Diameter

0.20mm

Min.Bonding Pad Diameter

0.20mm

Max.Proportion of Drilling Hole and Board Thickness

1:10

Max.Size of Finish Board

23inch*35inch

Rang of Finish Board′s Thickness

0.21-3.2mm

Min.Thickness of Soldermask

10um

Soldermask

Green,Yellow,Black,White,Red,transparent photosensitive solder mask,Strippable solder mask

Min.Linewidth of Idents

4mil

Min.Height of Idents

25mil

Color of Silk-screen

White,Yellow,Black

Date File Format

Gerber file and Drilling file,Report series,PADS 2000 series,powerpcb series,ODB++

E-testing

100%E-Test:High Voltage Testing

Material for PCB

High TG Material:High Frequence ROGERS,TEFLON,TADONIC,ARLON(Haloger free Material)

E-testing

Impedance Testing,Resisitance Testing,Microsection etc

Special Technological Requirement

Blind&Buried Vias and High Thickness Copper
