PCB PCBA Assembly Manufacture PCBA Service Customer Circuit Board

原图
Quick DetailsModel Number: CustomizedPlace of Origin: Guangdong, ChinaBrand Name: OEM ODMBase Material: FR-4Copper Thickness: 1ozBoard Thickness: 1.6mmMin. Hole Size: 0.20mmMin. Line Width: 3miMin. Line Spacing: 0.1um(3mil)Surface Finishing: HASLSolde…
Quote Now
Product Details

Quick Details

Model Number:
Customized
Place of Origin:
Guangdong, China
Brand Name:
OEM ODM
Base Material:
FR-4
Copper Thickness:
1oz
Board Thickness:
1.6mm
Min. Hole Size:
0.20mm
Min. Line Width:
3mi
Min. Line Spacing:
0.1um(3mil)
Surface Finishing:
HASL
Solder mask color:
Green Black Red
Material:
FR4 CEM1 CEM3 Hight TG
Type:
Customizable
Usage:
OEM Electronics
Supply Ability
Supply Ability
100000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
Gold Metal Detector PCB Circuit Board Design PCBA
packaging details:
Design file in zip format email delivered
Prototypes:
Inner packing: vacuum or anti-static bag
Port
Shenzhen Port

Gold Metal Detector PCB Circuit Board Design PCBA





We offer all kinds of Electronic Components (Modules,Cables ,Sensors,NTC, Aluminum heatsink/waterblock/copper tube/Thermoelectric Cooler,Switches,Crystal Oscillator and Connectors etc.) with a wide range, good quality, reasonable prices and stylish designs according to your need.

More quantity, please contact for best discount and postage.



One Station service for PCB,Aluminum PCB,FPC,PCBA ,Clone Boards,Stencil,Membrane Switch,Custom parts Production and Electronic Components Procurement, If you have any inquiry, pls feel free send us your requirments,we will make our best offer for you, thank you.





Product Description



Product Name PCB & PCBA
Type Customizable
Base Material FR-4
Copper Thickness 1oz
Board Thickness 1.6mm
Min. Hole Size 0.20mm
Min. Line Width 3mi
Min. Line Spacing 0.1um(3mil)
Surface Finishining HASL, ENIG, OSP, etc.
Solder mask color Green, Red, Blue, Yellow, etc.
Material FR-4, CEM1, CEM3, Hight TG
Usage OEM Electronics

Gold Metal Detector PCB Circuit Board Design PCBAGold Metal Detector PCB Circuit Board Design PCBAGold Metal Detector PCB Circuit Board Design PCBAGold Metal Detector PCB Circuit Board Design PCBA

PCB Design has the ability to complete your schematic capture and PCB layout in several

different software packages including:

• Cadence OrCAD/Allegro

• Altium PCAD

• Altium Designer



Gold Metal Detector PCB Circuit Board Design PCBA

• Acquire all information needed, reviewing and verifying the accuracy.

• Schematic capture and net list generation (if not done yet).

• Create part library for the project.

• PCB component placement.

• Submit intermediate placement to engineer for reviewing. This is usually a discussion-modification process until get approval on final placement.

• PCB routing. PCB designer and engineer must maintain adequate and frequent communication during the routing process.

• Complete PCB layout, finalize all documents.



Gold Metal Detector PCB Circuit Board Design PCBA

• Bill Of Materials (BOM).

• Final Net list.

• Hardcopy (or electronic version) of Schematics.

• Data sheets for special parts, if any.

• Any special instructions on layer stack-up (i.e. Signal, Ground & Power Planes) and plane splitting.

• Any drawing/detailed scratch showing board shape, size, and mounting mechanism, or heat sink, etc.

• Silkscreen text identification, including Part Numbers and Revisions.

• Any signals requiring special routing.

• Any placement requirements or restrictions (Placement ideas is greatly helpful.



Gold Metal Detector PCB Circuit Board Design PCBA

• PCB Design Files.

• Standard PCB fabrication files (Gerber & NC-Drill in standard formats).

• Schematics and BOM if the schematic capture process involved in the design order.

• Assembly drawings.

• Assembly machine pick-place data file.

• Solder paste stencil files.

• Other optional files as client required.



Gold Metal Detector PCB Circuit Board Design PCBA

• Provide as accurate information of circuit design and system requirement as possible.

• Avoid/minimize change on schematic after PCB layout process begins.

• Reducing density and making practical requirement.

• Choose responsible and highly skilled PCB designers.

• Schematics and BOM if the schematic capture process involved in the design order.

• Assembly drawings.

• Assembly machine pick-place data file.

• Solder paste stencil files.

• Other optional files as client required.



Gold Metal Detector PCB Circuit Board Design PCBA
