Product Details

Products Description

Item （PCB Assembly）	One-Stop OEM Service
Max Board Size	680550mm Smallest:0.25"0.25"
Min Components size	0201-54 sq.mm (0.084 sq.inch),Long Connector,CSP,BGA,QFP
Speed	0.15sec/chip, 0.7sec/QFP
Wave-Solder	Max.PCB Width:450mm
	Min.PCB Width:unlimited
	Components Height:Top 120mm/Bot 15mm
Sweat-Solder	Metal Types:Part,Whole,Inlay,Side-step
	Metal Material:Copper,Aluminum
	Surface Finish:Plating Au,Plating Silver,Plating Sn
	Air Bladder Rate:less than 20%
Assembly Types	SMT and Thru-hole
Solder Type	Water Soluble Solder Paste,Leaded and Lead-Free
File Formats	Bill of Materials ,Gerber Files,Pick-N-Place Files(XYRS)
Type of Service	Turn-Key,Partial Turn-Kye or Consignment
Component Packaging	Cut Tape,Tube Reels Loose,Parts
Turn Time	1-15 Days
Testing	XRAY Inspection,AOI Testing ICT,Flying Probe,Burn-in,Function Test
$0 for Prototype PCB Assembly	Layers: 1 & 2 & 4 Qty: 10 pcs Material: Rigid FR-4 Size: Within 100*100 mm Assembly Parts: Within 20 pcs
What is needed for PCBA quotation?	1.Gerber file & Bom list. 2.Clear pics of pcba or pcba sample for us. 3.Test method for PCBA.
